4.5-28x52mm High Master Wide Angle 1/10 Mil Click Exposed Tactical Knobs March FX D28HV52WFIML

Tactical Model (Illuminated)

March-FX “Wide Angle” 4.5-28x52mm Riflescope
This scope was developed with practical precision shooting competitors in mind, but ease of use and compact configuration make it equally at home on nearly any shooting platform. The short length (318mm; 12.5”) and light weight (845g; 29.8oz) of the March-FX 4.5x-28x52mm is exceptional.
・6.2X Zoom in FFP
・34mm diameter body
・52mm objective lens
・Wide Angle eyepiece : 25 degrees
・Temperature Anti-Drift Lens System
・High Master lens system (Super ED lenses)
・Side focus 10 yard – infinity
・Scope body fully machined from aluminum ingot
・All Japanese metal parts with no plastic part except for minimum essentials such as an insulator
・Argon gas filled for internal stability
・Fast focus eyepiece
・6 level illumination module

“Temperature Anti-Drift Lens System”
In the latest optical systems, a new lens material has been developed to accommodate changes in environmental temperature by altering the refractive index of the lenses. This new lens material has been adopted to create a more stable lens system that naturally adapts to changes in temperature to maintain focus and clarity over a wide range of conditions.

“Wide Angle Eyepiece”
25 Degree Wide Angle Eyepiece will enhance FOV throughout the 6.2 magnification range. Compared with our standard scopes with 20 degree, this is wider by 25%.

“Super ED lenses”
By incorporating Super ED lenses (High Master lens system), we are able to reduce the chromatic aberration.

“Fast focus eyepiece”
The diopter adjustment mechanism has been improved so you can adjust the eyepiece to your eye faster than ever before.

0.1 MIL Clicks

1 Click Adjustment : 0.1MIL (1cm @100m)
10 MIL turret revolution (100cm @100m)
0-set on Elevation turret
Elevation dial is a tactical type.
Windage dial is a normal(capped) type.
*6-level illumination module is a standard specification for this model.

Technical Data

		Low	High
Magnification		4.5x	28x
Effective Lens Diameter		52mm
Body Tube Diameter		34mm
Exit Pupil			1.86mm (0.73 inch)
Field of View (real)	degree	5.56°	0.892°
	ft/100yd	29.1ft	4.7ft
	m/100m	9.7m	1.56m
Eye Relief		70‐93.7mm	72‐90mm
1 Click Adjustment		0.1MIL
Elevation Travel		30MIL
Windage Travel		20MIL
Focus Distance		10yd – infinity
Reticle		FML‐TR1 FML‐3
In the box		Flip Caps (Objective and Eyepiece) Sunshade Lens Cloth MD disk Middle focus wheel Engraved Large dial Fast lever Hex key
Scope Size	A	318mm (12.5inch)
	B	129mm (5.0inch)
	C	60mm (2.4inch)
	D	46mm (1.8inch)
	E	93mm (3.7inch)
	F	96mm (3.8inch)
	G	42mm (1.6inch）
	H	49mm (1.9inch)
Weight		845g (29.8oz)
