5-40x56mm Gen2 FFP March-FX Illuminated 0.05 Mil Clicks Locking Turrets D40V56FIML-G2

Original price was: $4,240.00.Current price is: $4,028.00.

5-40x56mm Gen2 FFP March-FX Illuminated 0.05 Mil Clicks Locking Turrets D40V56FIML-G2

Available on backorder

SKU: D40V56FIML-G2 Categories: , Brand:

Description

5-40x56mm Gen2 FFP March-FX Illuminated 0.05 Mil Clicks Locking Turrets D40V56FIML-G2

March-FX 5-40×56 Genll
Generation ll of a hot seller and all time favorite 5-40×56 Scope with
precise 0.05MIL click adjustment. 5-40x56Genll is an ultimate scope for
serious competition shooters, enthusiasts and hunters who demand the
utmost in optical/mechanical performance.
・8X Zoom in FFP
・34mm diameter body
・56mm objective lens
・Side focus 10 yard – infinity
・Scope body fully machined from aluminum ingot
・All Japanese metal parts with no plastic part except for minimum essentials such as an insulator
・Argon gas filled for internal stability
・6 level illumination module

Added features in 5-40×56 Genll from the original 5-40×56 are;
・Lockable Elevation and Windage turrets
・Fast focus eyepiece
・6 level illumination module

First Focal Plane Reticle Scope (FFP)

A
feature of First Focal Plane design, also known as FFP, is the reticle
scale value does not change over the entire zoom range. Also the point
of aim (POA) does not change over the entire zoom range. Using the
reticle for ranging and also with trajectory drop charts is much
simplified. However, the reticle scale will get thicker when
magnification is increased. The special reticle design in the March
scope allows target acquisition quickly at both low and high
magnification.



Dials

D40V56FIML-G2 (MIL, Tactical, Illumi, 0.05MIL adj, Lock, Genll)

0.05 MIL Type

0.05MIL Adj.dials with 0-Set
One turn of both adjustment dials is 5MIL and one click value is 0.05MIL.



Reticles





Technical Data

Low High
Magnification 5x 40x
Effective Lens Diameter 56mm
Body Tube Diameter 34mm
Exit Pupil — 1.4mm
(0.06inch)
Field of View (real) degree 4.0° 0.5°
ft/100yd 21.0ft 2.6ft
m/100m 6.98m 0.87m
Eye Relief 96-100mm
(3.78-3.94inch)
92-98mm
(3.62-3.86inch)
1 Click Adjustment 0.05MIL
Elevation Travel 24MIL
Windage Travel 12MIL
Focus Distance 10yd – infinity
Reticle FML-1
FML-PDKI
In the box Flip Caps (Objective and Eyepiece)
Sunshade
Lens Cloth
Fast lever
MD disk
Hex wrench
Scope Size A 389mm (15.32inch)
size B 155mm (6.1inch)
C 64mm (2.52inch)
D 41mm (1.61inch)
E 146mm (5.75inch)
F 88mm (3.46inch)
G 66mm (2.6inch)
H 52mm (2.05inch)
Weight 925g (32.62oz)
